100kW/225kWh/200kW Energy storage charging stack(C&l parks)
Energy storage power stack is a highly integrated power device that combines photovoltaic (PV) inversion, energy storage conversion, energy management, and power distribution functions into a single unit. By integrating PV generation with battery storage, it enables local consumption of renewable energy, peak shaving and valley filling, backup power supply, and microgrid operation.
Send Inquiry
Product Description
Product features
1.100kW PCS power;
2.225kWh battery stack capacity;
3. Optionally configurable with 1×160kW single-gun terminal;
4. Optionally configurable with 4×40kW Dual-gun terminal; for rotational charging.
5. No additional transformer required,enabling one stack to support nine-gun application.
| Models | EC225-100k-5*40k-400-A | |
|
Battery parameters |
Celltype | LFP 314Ah |
| Pack capacity and configuration | 16.077kWh/1P16S | |
| Battery capacity and pack quantity | 225kWh/14 | |
| Battery voltage range | 672V-806V | |
| Charge/Discharge C-Rate | ≤0.5C | |
| Depth of discharge | 95%DOD | |
| Cycles index | 8000cls(0.5P,25±2℃,@70%SOH) | |
| Temperature monitoring points | 112 | |
|
PV Side parameters (MPPT Output Side) |
Maximum input power | 100kW |
| Maximum input current | 148A | |
| Voltage range | 672V-806V | |
|
Charging parameters |
Charging power | 200kW |
| Charging powerallocation | Dynamic switching | |
| Number of charging guns | Supports1×160kW Single gun+4×40kW Dual-gun | |
|
AC Side parameters |
AC rated power | 100kW |
| AC maximum power | 110kW | |
| AC current THDi | <3% | |
| DC component | <0.5%lpn | |
| System voltage standard | 400V | |
| Voltage range | 360VAC~440VAC | |
| Power factor | -1~1 | |
|
System parameters |
Advertising screen | 3”(optional) |
| Touch panel | 10“ | |
| Network connection type | 4G/WIFI/Etherlink | |
| Payment method | APP Card Authentication,VIN,APP | |
| Noise | <70dB | |
| Cooling system | Liquid-cooling battery system &Air cooling power modules | |
| IP grade | IP55(Complete machine) | |
| Operating temperature | -30～55℃ | |
| Relative humidity | 0-95%RH,Non-condensing | |
| Dimensions(L*D*H) | 1600×1050×2100mm | |
| Weight | 2600kg | |
| Corrosion resistance class | C3(Conventional),C5(Optional) | |
Hot Tags: Energy storage charging stack(C&l parks) 100kW/225kWh/200kW
